MJ153D Auto-feed rip saw點擊次數：2790 次
產品簡介及技術參數：
Widen tracked,Multiple sets of roller, feeding smoothly
Caterpillar pneumatic for dust cleaner
Four levels of the rebound devices more secure
Standard of pure copper wire motor power is strong
Caterpillar pneumatic for dust cleaner
Four levels of the rebound devices more secure
Standard of pure copper wire motor power is strong
 |
 |
|
Super mesa widened chain plate
|
Four groups of protection operation safety
|
 |
 |
|
Auxiliary roller precision is higher
Quenching rail longer life,Standard motor power is strong
|
0.10/2000mm Trimming precision |
| Technical Specification | Unit | MJ153D | MJ154D |
| Min. sawing length | mm | 230 | 260 |
| Sawing thickness | mm | 10-85 | 10-125 |
| Throat depth | mm | 460 | 610 |
| Saw blade diameter | mm | ?250-305 | ?305-405 |
| Spindle diameter | mm | ?25.4 | ?25.4 |
| Saw spindle speed | r/min | 4000 | 3500 |
| Main motor power | kW | 7.5 | 11 |
| Feeding motor power | kW | 1.5 | 2.2 |
| Feeding speed | m/min | 12.5/16/19.5/24 | 6~25 |
| Fixed table size | mm | 1100×1600 | 1230×1750 |
| Overall dimensions | mm | 1800×1100×1356 | 2100×1400×1500 |
| Net.weight | kg | 980 | 1200 |
